Quality Medical Supplies 1.5ata Hyperbaric Chamber Soft sitting type chamber ST2200

ST2200

Portable, easy to carry, install and operate.

Inside the chamber, you can listen to music,

read a book, use cell phones or laptops

Size:

220x70x110cm(89″x28″x43″)

Pressure:

1.3ATA

1.4ATA

1.5ATA

Model:

ST2200

Product Detail

Product Tags

225*Φ80cm (89*32inches)

225*70*110cm (89*28*43inches)

lying type soft chamber

sitting type soft chamber

without folding chair

with folding chair

2 zipper seal

3 zipper seal

7 large transparent viewing windows

4 large transparent viewing windows

Accommodate 1 person

Accommodate 2 person

Chamber material:

TPU + inner pocket nylon fiber (TPU coating + high strength nylon fiber) TPU coating plays a good sealing role, high-strength nylon fiber pressure resistance. And the material is non-toxic.After the SGS test.Other companies are PVC material, although not visible from the appearance, easy to age, brittle, not durable, poor quality.

Chamber Pressure:

ST801 model have three pressure mode for choose.

1.3ATA is the most people choose,

1.4ATA and 1.5ATA can be optional.

Sealing system:

Soft silicone + Japanese YKK zipper:

(1) daily sealing is good.

(2)when the power failure, the machine stops, the silicone material due to its own weight is relatively heavy, thus naturally sagging, and then the formation of a gap between the zipper, this time the air will be in and out, will not lead to suffocation problems.

Splicing pure TPU transparent window:
We use high-frequency heat welding (high-frequency welding) technology, non-composite, one-piece molding, the use of high-cost large mold.
Other companies' products are composite, using small molds, easy to leak.

Automatic Pressure Relief Valves:
The chamber pressure reaches the set pressure automatically constant, maintaining a steady state of pressure, eliminating pain in the ear and keeping the air oxygen flow. The higher the pressure, the greater the spring strength and hard ness required. The precision is high, accurate, and quiet.

Emergency Pressure Relief Valve:
(1) Realize the fast exit within 30S
(2) When the automatic constant pressure valve fails, it can achieve the role of pressure stabilization and pressure relief.

Manual pressure reducing valve:
(1) Adjustable both inside and outside.
(2) There are 5 levels of adjustment, and 5 holes can be adjusted to lift the pressure and relieve the discomfort of the ears.
(3) 1.5ATA and below can use it and open to 5 holes to achieve fast exit from the chamber (the feeling of the lungs is like surfacing from the bottom of the sea). But 2ATA and 3ATA are not recommended for this.

Mattress material:
(1) 3D material, millions of support points, perfectly fit the body curve, support the body curve, the human body for all-round support. In all directions, to achieve a comfortable sleep state.
(2) hollow three-dimensional structure, six-sided breathable, washable, easy to dry.
(3) The material is non-toxic, friendly to the environment, and passed the RPHS international test.

Metal Frame:
Stainless steel material, long service life, electroplating does not rust, truncated for easy transportation and carrying.

Folding chair:

Flexible and foldable structure, small size and easy to move.

Gold relies on the lying angle to release back pressure.

Ergonomic design, more suitable for cervical vertebrae.

Three options of breathing oxygen:

Oxygen mask

Oxygen headset

Oxygen nasal tube

Accessories

Oxygen concentrator BO5L/10L

One click start function

LED high-definition display

Real-time display

Optional timing function

Flow adjustment knob

Power outage fault alarm

Air compressor

One-key start function

Flow output up to 72Lmin

Optional negative ion

Filtration system

Air dehumidifier

Advanced semiconductor refrigeration technology

Reduces air temperature by 5°C

Reduces humidity by 5%

Able to operate stably in high-pressure
